XT60 APM parts with DC 5.3V BEC for Flight Controller APM 2.5, 2.5.2, 2.6 Pixhawk Accessories ht

XT60 APM parts with DC 5.3V BEC for Flight Controller APM 2.5, 2.5.2, 2.6 Pixhawk Accessories ht
  • Stock: In Stock
  • Brand: xcluma
  • Model: BE-002150
  • Weight: 25.00g
  • SKU: BE-002150
  • MPN: BE-002150
Rs485.00
(GST +18%Extra)

XT60 APM parts with DC 5.3V BEC for Flight Controller APM 2.5, 2.5.2, 2.6 Pixhawk Accessories ht

Features:
1.A simple way to provide your APM 2.5 / 2.52 / 2.6 and Pixhawk with clean power from a LiPo battery as well as measurements
of current
2.the onboard outputs regulator switching the source of 5.3 V and a maximum of 2.25A of up to a 4S LiPo battery.
3.Used to detect battery voltage and battery current, flight control board receives two signals, calculate remaining battery
 charge, estimate remaining flight time.
4.comes with the BEC function, you can produce 5.3 DC, maximum 3A DC current for the flight control board to provide a
stable power supply.
5.connectors are used in Japan original accessories, non-household common, to APM flight control board and
reliable connection between the power supply module.

Description:
1.This is XT60 APM Power Module
2.It it suitable for APM 2.5 / 2.5.2 / 2.6 Pixhawk
3. A good choice for you to get clean power from a LiPo battery!

Specifications:
Item name: APM Power Module
maximum input voltage: 20 V
Max current detection: 90A-
voltage and current measurement set to 5 V ADC
switching outputs regulator 5.3 V and 2.25A max
cable is connected directly to the APM DF13 6-pos \\\'PM\\\' of the 2.5 connector
Product Size: 142*21*10mm
Weight:22g

Package Included:
1 x Power Module
